Description
Instantaneous DHE production module with programmable electronic control unit and high-efficiency modulating circulator.
Designed for direct connection to hot water buffer vessels, it makes it possible to use the stored energy to ensure a high production of DHW at a controlled temperature that can be fully adjusted by the user.
The thermal stability of ASAP fresh water station is obtained by automatically varying the flow rate of the primary circulator, thus controlling the temperature of the return to the storage tank and favouring the best performance for each type of generator connected. The thermostat function, present in the internal logic of the control unit, makes it possible to control its start-up when necessary.
The main components are:
- High efficiency AISI 316L brazed plate heat exchanger
- Electronic modulating circulator for the primary hot water circuit
- High efficiency electronic circulator for the domestic hot water circulation circuit (where applicable)
- Digital flow sensor that constantly monitors the flow rate and temperature values of the production of DHW
- Electronic control unit for total management of operating parameters
Construction features
The regulation options available allow all the variables necessary for the production and distribution of hot water to be set and fully adapted to the needs of each system, with values constantly monitored and displayed on the digital graphic display for easy consutation.
The system also allows energy consumption to be checked at definable intervals and the temperature and operating hours of the circulation circuit to be programmed, if present.
It is completely thermally insulated and housed in an extremely compact box with a metal back plate for wall or tank mounting.
