Description
The BV brazed plate heat exchangers are suitable for a very wide range of uses and represent an excellent solution for thermo-hydraulic systems and industrial appcations.
Made from AISI 316L stainless steel plates brazed with 99.99% pure copper, equipped as standard with GAS male threaded connections.
The robust means of construction and the use of high-quality materials enable high operating pressures and an extremely wide of temperatures to be guaranteed, expanding of use even to particularly harsh operating conditions.
They are available in 4 sizes with connections from ¾" to 2".
All models except the BV18 can be supplied with 2 different types of plate corrugation pattern
- H (High performance, high pressure drop)
- L (Low performance, low pressure drop
to allow the characteristics of the system to be calibrated in the best possible manner and obtain the maximum posible output.
The extreme flexibility of the BV brazed heat exchangers is enhanced with the range of specific accessories that satisfy every type of application; it is possible to choose between different types of insulation (both thermal and anti-condensation) with various types of external cladding and to assess the convenience of adopting the support brackets for fixing to wall which have been specifically dsigned for supporting the heat exchanger, even if fitted with the relative insulation..
