Description
Calorifiers made of galvanised steel with one removable tube bundle heat exchanger for production and storage of DHW. Designed for connection to a steam or overheated water primary energy source.
The calorifiers of the BTVH-Z | BTV-Z range are equipped with removable tube bundle heat exchangers made of Stainless Steel AISI 316L and compliant with PED 2014/68/EU. These batteries are designed to be used when primary media is steam or overheated water and are available in two different options: Primary up to 6 bar (165°DegC) or Primary up to 12 bar (191,7°DegC). They can be either CE marked or not, according to the operation conditions and relevant assessed PED category, if applicable.
The calorifiers of the BTVH-Z | BTV-Z range stand out for the wide choice of capacities, from 300 to 5000 L as standard and over upon request.
They are available, in the larger sizes, in vertical-low and vertical extra-low versions to allow them to be installed in circumstances where the available height is not sufficient for the standard measurement.
The possibility of selecting between various operating pressures - up to 10 bar - and the availability of different external claddings for indoor or outdoor installation, extends their use to all the possible applications.
Protection from galvanic currents is provided by the electronic anodes fitted as standard, which both save on costs of checking and replacing conventional magnesium anodes and ensure superior reliability and durability.
